Description
Output
Max Configurable Power (Watts): 1.6kWatts /Â 2.0kVA
Output Voltage Note: Configurable for 220 : 230 or 240 nominal output voltage
Efficiency at Full Load: 88.0 %
Output Frequency (sync to mains): 50/60 Hz +/- 3 Hz Sync to mains
Other Output Voltages: 220, 240
Load Crest Factor: 3 : 1
Topology: Double conversion online
Waveform type: Sine wave
Bypass: Internal bypass (automatic and manual)
Input
Input frequency: 40 – 70 Hz
Input voltage range for main operations: 110 – 285 Adjustable (half load), 160 – 280V
Number of Power Cords: 1
Efficiency at Full Load: 88.0 %
Other Input Voltages: 220, 240
Batteries & Runtime
Battery type: Lead-acid battery
Typical recharge time: 4 hour(s)
Battery Charge Power (Watts): 76Â Watts
Runtime: View Runtime Graph
Efficiency: View Efficiency Graph
Communications & Management
Interface Port(s): DB-9 RS-232, USB
Control panel: Multifunction LCD status and control console
Audible Alarm: Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Surge Protection and Filtering
Surge energy rating: 600 Joules
Physical
Maximum Height: 238MM, 23.8CM
Maximum Width: 145MM, 14.5CM
Maximum Depth: 400MM, 40.0CM
Net Weight: 16.8KG
Shipping weight: 18.1KG
Shipping Height: 355MM, 35.5CM
Shipping Width: 235MM, 23.5CM
Shipping Depth: 525MM, 52.5CM
Color: Black
Environmental
Operating Temperature: 0 – 40 °C
Operating Relative Humidity: 0 – 95 (Non-condensing) %
Operating Elevation: 0 – 3000meters
Storage Temperature: -20 – 50 °C
Storage Relative Humidity: 0 – 95 (Non-condensing) %
Storage Elevation: 0 – 15000meters
Audible noise at 1 meter from surface of unit: 50.0dBA
Protection Class: IP20
Conformance
Approvals: CE, EAC, IEC 62040-1-1, IEC 62040-1-2
Standard warranty: 2 years repair or replace
Sustainable Offer Status
RoHS: Compliant
